EverSharp Mode
EverSharp mode utilizes the focus motor to capture multiple images from varying focal distances with the push of a button. Using special algorithms, SmartView® software will combine images taken from multiple focal distances and will create an image that sharpens the detail of not just the initial focal point, but also enhances the focus of the elements around the focal point. These infrared images turn out very impressive as all objects are then displayed in superb image quality.

Subwindowing
Sudden and rapid temperature changes can be a critical part of certain analysis. The TiX660, and other Fluke Expert Series cameras, provide an optional Subwindowing mode (available at time of camera purchase). This feature is usually found only in cooled infrared cameras. Using these infrared sequences allows the user to document and analyze many frames of data per second to better understand sudden temperature changes.

SuperResolution provides 4x the resolution that's available on camera. Select the SuperResolution mode before you capture images. Then transfer them to the included SmartView® software and select the SuperResolution mode to reveal 3,145,728 pixels and see infrared in a whole new way.

Built with Fluke Connect™
Fluke Connect with ShareLive™ video call is the only wireless measurement system that lets you stay in contact with your entire team without leaving the field.

The Fluke Expert Series offers the best flexibility of the entire Fluke infrared camera portfolio to capture spectacular images close up or from a distance. The TiX660 is compatible with eight lens options (2x and 4x telephoto lenses, 2 wide angle lenses, 3 macro lenses, and 1 standard lens).

Fluke Expert Series

• 60 Hz HD infrared camera with Fluke Connect™ technology; 640 x 480 (307,200 px.)
• FOV: 30.9° x 23.1° (30 mm lens)
• Temperature range: -40 to 2000°C (-40 to 3632°F)
• Work from greater distances. See a 8 mm target from 35 m using the Super Telephoto lens
• 8 MP visible light camera
• Versatile viewing options for in-field viewing of images with viewfinder for outdoor use
• Can be sub-windowed to 240 Hz frame rate for advanced applications (add-on option)
• Get a premium in-field viewing experience for quick issue identification with the large 5.6" high-resolution LCD screen
• Viewfinder: Tiltable LCoS color viewfinder display, 800 x 600 pixel resolution
• Enhanced image quality and temperature measurement accuracy; 4 times the resolution and pixels than standard mode with SuperResolution
• Advanced focus options for consistently in-focus images: LaserSharp® Auto Focus, auto focus, manual and EverSharp multifocal recording features
• Compatible with 8 lens options (2x and 4x telephoto lenses, 2 wide angle lenses, 3 macro lenses, and 1 standard lens)
• Convenient image transfer protocols: SD card, USB 2.0, video output DVI-D (HDMI), SmartView® - GigE Vision and RS232

Optional lenses must be calibrated to the individual camera. If lens is purchased later, the camera will need to be returned for calibration with the lens. The Fluke TiX660 ships with FLK-Xlens/Stan 30 mm lens. In addition to these wide angle and telephoto lenses, three Macro Lenses are available for the 30 mm and 60 mm lenses. Please refer to Data Sheet for complete specifications.

Included:

• Two (2) rechargeable batteries
• Battery charger and adapter
• AC adapter
• SD card
• SD card reader
• Protective lens cap
• Hand strap
• Neck strap
• Carrying case
• Warranty card
• Safety instructions and calibration certificate
• CD includes product manuals and SmartView® software.
