Product Description

The XL5 is the newest and most advanced member of the Niton family of portable X-ray fluorescence (XRF) analyzers. It is purpose-built to verify metal alloys for manufacturing quality assurance and control; achieve positive material identification in seconds; and perform accurate elemental analysis for scrap metal recycling operations.

Advanced analytical performance – lower LODs and faster measurement times
Light weight - only 2.8 lbs. (1.3 kg.) reduces operator fatigue and increases productivity
Expanded field use – compact geometry reaches corner welds and tight test spots
Large alloy library - increases coverage; an internal calibration standard ensures accuracy.
A micro and macro camera - allows more precise positioning of the analyzer on the sample while capturing an entire sample image for better record keeping.
Custom profiles - for specific analysis requirements for alloy ID only, or manager/operator profiles.

Product Size

	-
Applications	31 most common elements for rapid alloy identification Ultra-low light element detection 31 most common elements for rapid alloy identification Ultra-low light element detection
Available Analytical Modes	Alloy Modes: Metal Alloy
Compliances	CE, RoHS, FCC, Industry Canada, Safety to UL/CSA/IEC 61010-1:2010
Data Storage	Internal >100,000 readings with spectra
Data Transfer	USB, Bluetooth
Description	XL5 Analyzer
Detector Type	Geometrically Optimized Large Area Drift Detector (GOLDD)Proprietary detector with 180,000 throughput cps Resolution: < 185 eV @ 60,000 cps @ 4µ sec shaping time Geometrically Optimized Large Area Drift Detector (GOLDD)Proprietary detector with 180,000 throughput cps Resolution: < 185 eV @ 60,000 cps @ 4µ sec shaping time
Display Type	Tilting, color, touch-screen display
Optional Accessories	3mm small-spot collimation Thermo Scientific™ portable test stand HotFoot hot surface adapter HotFoot Jacket HotWork stand off 3mm small-spot collimation Thermo Scientific™ portable test stand HotFoot hot surface adapter HotFoot Jacket HotWork stand off
Security Features	Password-protected user security
Standard Accessories	Integrated CCD camera for locating and storing images Locking shielded carrying case Belt holster Two lithium-ion battery packs 110/220 VAC battery charger/AC adaptor PC connection cables (USB) Niton Data Transfer (NDT) PC software Safety lanyard Check samples/standards Integrated CCD camera for locating and storing images Locking shielded carrying case Belt holster Two lithium-ion battery packs 110/220 VAC battery charger/AC adaptor PC connection cables (USB) Niton Data Transfer (NDT) PC software Safety lanyard Check samples/standards
Tube Type	Ag anode (6-50 kV, 0-500 µA max)
Weight (English)	2.8 lbs with battery
Weight (Metric)	1.3 kg
System Electronics	533 MHz ARM 11 CPU300 MHz dedicated DSP 80 MHz ASICS DSP for signal processing 4096 channel MCA iMX6 quad core ARM A9 running at 900 MHz 512 MB internal system memory / 4 GB industrial grade storage 533 MHz ARM 11 CPU300 MHz dedicated DSP 80 MHz ASICS DSP for signal processing 4096 channel MCA iMX6 quad core ARM A9 running at 900 MHz 512 MB internal system memory / 4 GB industrial grade storage
Data Entry	Touch-screen keyboard User-programmable pick lists Optional wireless remote barcode reader Touch-screen keyboard User-programmable pick lists Optional wireless remote barcode reader
Licensing	Varies by region. Contact your local distributor.
Dimensions (L x W x H)	9.54 x 8.19 x 2.67 in. (242.56 x 208.17 x 67.9mm)
